编号（REF）
|
数量(Qty)
|
件号(Part No)
|
品名(Part Name)
|
|
B4
|
1
|
45Z91D104
|
O-RING
|
|
B3
|
4
|
ZW26K12000
|
LOCK WASHER
|
|
B2
|
4
|
ZS28C12030
|
CAP
|
|
B1
|
1
|
YN30H01220P1
|
ELBOW
|
|
|
AR
|
YN30H00044F1
|
Hyd, Pump
|
|
A19
|
2
|
ZC16X10000
|
CLIP
|
|
A17
|
4
|
ZD12P03400
|
O-RING
|
|
A15
|
3
|
ZW16H12000
|
WASHER
|
|
A14
|
3
|
ZS18C12090
|
SCREW Cap
|
|
A13
|
16
|
HM83C12040G1
|
BOLT Sems
|
|
A12
|
2
|
ZC16X09100
|
CLIP
|
|
A11
|
3
|
ZY26X06056
|
SPACER
|
|
A10
|
8
|
ZE13X16000
|
FLANGE Clamp, Half
|
|
A6-2
|
1
|
ZD12P01400
|
O-RING ID 10.80 ± 0.18 x OD 15mm
|
|
A9
|
1
|
YN30H01215P1
|
PLATE
|
|
A6-1
|
1
|
LS30H01024P1
|
HYD CONNECTOR (Added with new part # press switch)
|
|
A8
|
1
|
YN30H01217P1
|
PLATE
|
|
A6-0
|
1
|
YY52S00033F1
|
SENSOR Kit Includes Ref 9 - 9-3 (Refer to SB S030-41-K003)
|
|
A7
|
2
|
YN30H01214P1
|
RUBBER
|
|
A6
|
2
|
LS52S00015P1
|
SENSOR Press (h.P.) (Added by SB S030-41-K003), ASN YN11-49207
|
|
A6
|
2
|
LS52S00015P1
|
SENSOR Press (h.P.) (Added by SB S030-41-K003), ASN YQ11-06414
|
|
A6
|
2
|
YN52S00048P1
|
SENSOR Press (h.P.), BTW YN11-45001 & YN11-49206
|
|
A6
|
2
|
YN52S00048P1
|
SENSOR Press (h.P.), BTW YQ11-06001 & YQ11-06413
|
|
A5-1
|
1
|
ZD12P01100
|
O-RING
|
|
A5
|
2
|
ZE72X04000
|
PLUG
|
|
A4-1
|
1
|
ZD12P02400
|
O-RING
|
|
A4
|
1
|
ZH32X12000
|
HYD CONNECTOR Elbow
|
|
A3
|
1
|
YN30H01196P1
|
HOSE
|
|
A2
|
1
|
YN30H01219D1
|
HOSE
|
|
A1
|
1
|
YN30H01247D1
|
HOSE , ASN YN11-48619
|
|
A1
|
1
|
YN30H01247D1
|
HOSE , ASN YQ11-06355
|
|
A1
|
1
|
YN30H01212D1
|
HOSE [ B ], BTW YN11-45001 & YN11-48618
|
|
A1
|
1
|
YN30H01212D1
|
HOSE [ B ], BTW YQ11-06001 & YQ11-06354
|
|
|
AR
|
YN30H00043F1
|
Hyd, Pump
|
|
|
AR
|
YN30H00041F1
|
Hyd, Pump
|
|
A6-3
|
1
|
YT42H01128P1
|
ELBOW (Added with new part # press switch)
|
|
37
|
1
|
2441U1040S32
|
BEARING ASSY
|
|
