编号（REF）
|
数量(Qty)
|
件号(Part No)
|
品名(Part Name)
|
|
K
|
1
|
YN15V00037R460
|
REPAIR KIT Kit, Repair -- Contains Items 107 & 108
|
|
K
|
1
|
YN15V00037R450
|
SEAL KIT Contains Items 31, 132, 135, 139, 329, 369, 371, 375, 379 & 380
|
|
K
|
1
|
YN15V00037R440
|
VALVE Kit, Repair -- Contains Items 323, 326-328 & 331
|
|
K
|
1
|
YN15V00037R430
|
VALVE Kit, Repair -- Contains Items 301, 323, 341, 343, 345 & 363-380
|
|
K
|
1
|
YN15V00037R420
|
PLATE Kit, Repair -- Contains Items 103 & 167
|
|
K
|
1
|
YN15V00037R410
|
PISTON Kit, Repair -- Contains Items 161 & 163
|
|
K
|
1
|
YN15V00037R400
|
PISTON Kit, Repair -- Contains Items 105 & 106
|
|
399
|
1
|
NSS
|
NOT SERVICED SEPARATELY Name Plate
|
|
398
|
4
|
YN15V00037S398
|
Pin
|
|
397
|
1
|
NSS
|
NOT SERVICED SEPARATELY Name Plate
|
|
380
|
1
|
YN15V00037S380
|
O-RING
|
|
379
|
1
|
ZD12P01600
|
O-RING ID 15.80 ± 0.20 x OD 20mm
|
|
378
|
3
|
YN15V00017S026
|
SPRING
|
|
377
|
3
|
YN15V00017S017
|
CHECK VALVE
|
|
376
|
3
|
YN15V00037S376
|
ORIFICE
|
|
375
|
6
|
ZD12P00800
|
O-RING ID 07.80 ± 0.16 x OD 11mm
|
|
374
|
5
|
YN15V00017S038
|
PLUG
|
|
369
|
2
|
ZD12P01100
|
O-RING ID 10.80 ± 0.18 x OD 15mm
|
|
368
|
2
|
2436U1317S13
|
PLUG
|
|
345
|
15
|
2436U1427S25
|
PLUG
|
|
341
|
1
|
YN15V00017S033
|
PIN
|
|
323
|
1
|
NSS
|
NOT SERVICED SEPARATELY Spool
|
|
301
|
1
|
YN15V00037S301
|
FLANGE
|
|
167
|
2
|
NSS
|
NOT SERVICED SEPARATELY Shaft
|
|
163
|
1
|
NSS
|
NOT SERVICED SEPARATELY Seal
|
|
162
|
1
|
YN15V00037S162
|
BALL
|
|
161
|
1
|
NSS
|
NOT SERVICED SEPARATELY Piston
|
|
150
|
1
|
YN15V00037S150
|
BEARING Roller
|
|
149
|
1
|
YN15V00037S149
|
BEARING Roller
|
|
139
|
1
|
YN15V00037S139
|
RING O-Ring
|
|
5月17日
|
1
|
2436U1749S17
|
PLUG
|
|
5月16日
|
1
|
2436U279S3
|
PLUG 1/16" Socket
|
|
5月14日
|
1
|
YN15V00037S135
|
RING
|
|
5月12日
|
1
|
YN15V00009S019
|
RING Retaining
|
|
5月11日
|
1
|
YN15V00009S027
|
OIL SEAL
|
|
4月28日
|
1
|
YN15V00037S119
|
SHIM
|
|
4月25日
|
4
|
YN15V00037S116
|
PLATE Separator
|
|
4月24日
|
3
|
YN15V00037S115
|
PLATE Friction
|
|
4月23日
|
9
|
YN15V00037S114
|
SPRING
|
|
Apr-00
|
8
|
YN15V00037S113
|
SPRING
|
|
Apr-00
|
1
|
YN15V00037S112
|
PISTON
|
|
Apr-00
|
1
|
YN15V00037S109
|
PLATE
|
|
Apr-00
|
1
|
YN15V00037S099
|
Ball
|
|
Apr-00
|
1
|
YN15V00037S098
|
PLATE Plate
|
|
Apr-00
|
9
|
NSS
|
NOT SERVICED SEPARATELY Shoe
|
|
Apr-00
|
9
|
NSS
|
NOT SERVICED SEPARATELY Piston
|
|
Apr-00
|
1
|
YN15V00037S104
|
CYLINDER Block
|
|
Apr-00
|
1
|
NSS
|
NOT SERVICED SEPARATELY Plate
|
|
Apr-00
|
1
|
YN15V00037S102
|
SHAFT
|
|
Apr-00
|
1
|
YN15V00037S101
|
SPINDLE
|
|
Feb-00
|
1
|
ZR26X03200
|
SNAP RING Retaining -- ID 32 x OD 34.4 x Th 1.2mm
|
|
35
|
18
|
ZS23C10035
|
SCREW M10x1.50x35mm
|
|
31
|
3
|
ZD12P01800
|
O-RING ID 17.80 ± 0.21 x OD 22mm
|
|
30
|
3
|
2441U995S121
|
PLUG
|
|
29
|
1
|
YN15V00037S029
|
SEAL Floating
|
|
28
|
3
|
YN15V00037S028
|
BEARING Needle
|
|
27
|
3
|
YN15V00037S027
|
BEARING Needle
|
|
24
|
2
|
YN15V00037S024
|
BALL BEARING Ball
|
|
23
|
1
|
YN15V00037S023
|
SHIM
|
|
22
|
2
|
YN15V00037S022
|
HALF-RING
|
|
17
|
3
|
YN15V00037S017
|
PIN Parallel
|
|
16
|
3
|
YN15V00037S016
|
PIN Parallel
|
|
15
|
1
|
YN15V00037S015
|
COUPLING
|
|
14
|
1
|
YN15V00037S014
|
COVER
|
|
13
|
1
|
YN15V00037S013
|
PLATE Thrust
|
|
12
|
6
|
YN15V00037S012
|
WASHER Thrust
|
|
11
|
6
|
YN15V00037S011
|
WASHER Thrust
|
|
Jan-00
|
3
|
YN15V00037S010
|
PIN Carrier
|
|
Jan-00
|
3
|
YN15V00037S009
|
GEAR Planetary
|
|
Jan-00
|
1
|
YN15V00037S007
|
GEAR Carrier
|
|
Jan-00
|
3
|
YN15V00037S006
|
PIN Carrier
|
|
1月5日
|
3
|
YN15V00037S005
|
GEAR Planetary
|
|
1月4日
|
1
|
YN15V00037S004
|
GEAR Sun
|
|
1月3日
|
1
|
YN15V00037S003
|
FLANGE Carrier
|
|
1月1日
|
1
|
YN15V00037S001
|
HUB Hub
|
|
1月8日
|
1
|
YN15V00037S008
|
GEAR Sun
|
|
|
AR
|
YN15V00037F2
|
HYDRAULIC MOTOR Propelling -- Used from date 02/22/2008 - Up, Figure 1 of 2
|
