编号（REF）
|
数量(Qty)
|
件号(Part No)
|
品名(Part Name)
|
|
|
AR
|
LS22TU0003F1
|
INSTALLATION, NAME PLATE - Mass Excavator
|
|
3
|
1
|
YN20TU1013P1
|
LABEL Decal, American Flag
|
|
|
AR
|
YN22TU0005F1
|
INSTALLATION, NAME PLATE
|
|
2
|
1
|
YN20TU1004P1
|
LABEL Installation of Vandalism Guards
|
|
|
AR
|
YN22TU0003F1
|
INSTALLATION, NAME PLATE
|
|
1
|
1
|
LC20T01016P1
|
LABEL Caution, Engine Oil Pan Drain Plug
|
|
|
AR
|
LS22T00021F1
|
INSTALLATION, NAME PLATE
|
|
4
|
2
|
LS22TU0002P2
|
LABEL DECAL - Mass Excavator
|
|
11
|
1
|
YN20T01419D2
|
LABEL Striping, Left Hand Side
|
|
10
|
1
|
2432Z929
|
LABEL Lubrication Labels, Not Illustrated
|
|
9
|
1
|
YN20T01317P2
|
LABEL Decal, Dynamic Acera logo (Left Side)
|
|
6
|
1
|
YN20T01418D4
|
LABEL Decal, Strip 855mm Long (33-21/32 in), Right Hand Side
|
|
5
|
1
|
YN20T01420D2
|
LABEL Striping and Dynamic Acera, Right Hand Side
|
|
4
|
2
|
YN20T01418D6
|
LABEL Decal, Strip 1240mm Long (48-13/16 in)
|
|
3
|
4
|
YN20T01282P1
|
SHEET Anti-Slip (230x105mm)
|
|
2
|
10
|
2427Z329D2
|
SHEET Anti-Slip (400x150mm)
|
|
1
|
1
|
LS20T01056P1
|
LABEL DECAL - Lubrication Chart
|
|
|
AR
|
LS22T00020F6
|
NAME PLATE INSTALLATION
|
|
8
|
2
|
LS22T00012P1
|
PLATE DECAL - Model Designation
|
|
1
|
2
|
YN22T00244P1
|
TYPE PLATE Decal, KOBELCO Logo
|
|
|
AR
|
LC22T00017F1
|
LABEL INSTALLATION, NAME PLATE
|
|
2
|
2
|
YN20T01337P1
|
LABEL Decal, Danger, Keep Clear of Machine
|
|
A32
|
1
|
YN20T01639P1
|
LABEL Decal, Caution, Swing parking brake release switch is installed on the rear side this cover., F5 Only
|
|
A31
|
1
|
YN20T01517P1
|
LABEL Caution, Emergency Manual Throttle Control Cable, F4 ONLY
|
|
A29
|
1
|
YN20T01039P1
|
LABEL Decal, Warning, This machine equipped with a rotary multi-control valve which allows changing of…, F4 ONLY
|
|
A28
|
1
|
YN20T01476P1
|
LABEL Decal, Control location and positions - SAE Pattern, F4 ONLY
|
|
A27
|
1
|
YN20T01475P1
|
LABEL Holder, F4 Only
|
|
A25
|
1
|
PY20T01073P1
|
LABEL Decal, Warning, Machine may move suddenly and cause serious …, F4 - F5 Only
|
|
A24
|
1
|
YN20T01339P1
|
LABEL Decal, Caution -- Be careful not to pinch your hand(s) when operating the lever., F4 - F5 ONLY
|
|
A22
|
1
|
YN20T01414P1
|
LABEL Decal, Caution - Maintenance - (when using nibbler or breaker) …, F2 ONLY
|
|
A21
|
1
|
YT20T01054P1
|
LABEL Decal, Caution - Do not set this switch to nibbler combined flow operation …, F2 ONLY
|
|
A20
|
1
|
PY20T01062P1
|
LABEL Decal, Caution - Attachment operation by foot pedal. Always check the …, F2 Only
|
|
A19
|
1
|
YY20T01039P1
|
LABEL Decal, Caution, Procedure to change selector valve…, F2 ONLY
|
|
A18
|
1
|
YN20T01416P1
|
LABEL Decal, Caution, Falling front window can cause injury (no picture), F4 - F5 ONLY
|
|
A17
|
1
|
YN20T01058P1
|
PLATE Decal, ITCS, F4 - F5 Only
|
|
A16
|
1
|
YN20T01407P1
|
LABEL Decal, Kobelco Construction Machine Co. LTD., F4 - F5 Only
|
|
A15
|
1
|
YT20T01072P1
|
LABEL Decal, Control location and positions, F5 ONLY
|
|
A14
|
1
|
YN20T01341P1
|
LABEL Decal, Control lockout, F4 - F5 ONLY
|
|
A13
|
2
|
PH20T01018P1
|
LABEL Decal, Hammer Hand and Man running, F4 - F5 ONLY
|
|
A12
|
1
|
YN20T01007P1
|
LABEL Decal, Notice, Stopping engine without allowing it to cool …, F4 - F5 ONLY
|
|
A11
|
1
|
YN20T01415P1
|
LABEL Decal, Caution, The KPSS work mode release switch …, F4 ONLY
|
|
A10
|
1
|
2432P3380
|
LABEL Decal, Caution, Bucket can contact and damage cab when mahine …, F4 - F5 ONLY
|
|
A9
|
1
|
YN20T01263P1
|
LABEL Decal, Caution, - Slow or unexpected movement…, F4 - F5 ONLY
|
|
A8
|
1
|
2432T6109
|
LABEL Decal, Warning, Do not install any object on the handrail. This can cause …, F4 - F5 ONLY
|
|
A7
|
1
|
2432T6457
|
LABEL Decal, Warning, California proposition 65, Diesel …, F4 - F5 ONLY
|
|
A6
|
1
|
YN20T01340P1
|
LABEL Decal, Warning -- Turning off heavy lift switch …, F4 - F5 ONLY
|
|
A5
|
1
|
YN20T01004P1
|
LABEL Decal, Warning, Releasing power boost switch while lifting a load can cause …, F4 - F5 ONLY
|
|
A4
|
1
|
2432T6110
|
LABEL Decal, Warning, Extreme high pressure in truck adjustment cylinder …, (F4 - F5 ONLY)
|
|
A2
|
1
|
YN20T01016P1
|
LABEL Decal, Warning, Read and understand operator manual before …, F4 - F5 ONLY
|
|
A1
|
1
|
YN20T01006P1
|
LABEL Decal, Danger, Contact with electrical power lines will result in …, F4 - F5 ONLY
|
|
F5
|
AR
|
YN22T00129F5
|
DECAL KIT INSTALLATION, NAME PLATE - Standard
|
|
F4
|
AR
|
YN22T00129F4
|
INSTALLATION, NAME PLATE - Pattern Changer
|
|
F2
|
AR
|
YN22T00129F2
|
PLATE INSTALLATION, NAME - Nibber and Breaker
|
|
A3
|
1
|
YN20T01048P1
|
LABEL Decal, Warning, Automatic two speed travel system changes travel speed …, F4 - F5 ONLY
|
|
13
|
1
|
YN20T01009P1
|
LABEL Decal, Warning, Rotating parts can cause personal injury…
|
|
12
|
1
|
YN20T01010P1
|
LABEL Decal, Warning, Steam of hot coolant can cause injury or blindness…
|
|
11
|
1
|
YN20T01015P2
|
LABEL Decal, Warning, Improper booster cable connection can cause an explosion…
|
|
10
|
1
|
YN20T01214P1
|
LABEL Decal, Danger, Stop the engine without fail at time of changeover…, F2 Only
|
|
9
|
1
|
YN20T01485P1
|
LABEL Decal, SAE, F2 ONLY
|
|
8
|
2
|
YN20T01003P2
|
LABEL Decal, Danger, Keep clear of swing area …
|
|
7
|
1
|
2432P3055
|
LABEL Decal, No Step
|
|
6
|
1
|
YN20T01028P1
|
LABEL Decal, Lift eyes or tank can fail when lifting tank containing fluids and …
|
|
5
|
1
|
YN20T01405P1
|
LABEL Decal, Warning, Pressurized hot oil can cause burns. Depress stem or …
|
|
3
|
2
|
YN20T01221P1
|
LABEL Decal, Danger, Do not use counterweight lifting eyes to lift whole machine…
|
|
2
|
1
|
YN22T00244P1
|
TYPE PLATE Decal, KOBELCO Logo, Rear of Machine
|
|
F2
|
AR
|
YN22T00271F2
|
NAME PLATE INSTALLATION - Pattern Changer
|
|
F1
|
AR
|
YN22T00271F1
|
NAME PLATE INSTALLATION - Standard
|
|
4
|
1
|
2432T6111
|
LABEL Decal, Warning, When servicing or repairing machine. Keep surface free of oil…
|
|
2
|
2
|
YN20T01337P1
|
LABEL Decal, Danger, Keep Clear of Machine
|
|
1
|
2
|
YN22T00244P1
|
TYPE PLATE Decal, KOBELCO Logo
|
|
|
AR
|
LC22T00017F1
|
LABEL
|
|
16
|
1
|
YN20T01418D6
|
LABEL Decal, Strip 1240mm Long (48-13/16 in)
|
|
15
|
2
|
LC22T00036P1
|
LABEL
|
|
13
|
1
|
2432Z929
|
LABEL Lubrication Labels
|
|
12
|
1
|
YN20T01419D2
|
LABEL
|
|
10
|
1
|
YN20T01317P2
|
LABEL Decal, Dynamic Acera logo (Left Side)
|
|
7
|
2
|
YN20T01418D2
|
LABEL Decal, Strip 225mm Long (8-55/64 in)
|
|
5
|
1
|
YN20T01420D2
|
LABEL
|
|
4
|
1
|
YN20T01418D5
|
LABEL Decal, Strip 1095mm Long (43-7/64 in) - Right side shorted than Ref 16
|
|
3
|
4
|
YN20T01282P1
|
SHEET Anti-Slip (230x105mm)
|
|
2
|
10
|
2427Z329D2
|
SHEET Anti-Slip (400x150mm)
|
|
1
|
1
|
LC20T01103P1
|
LABEL - Lubrication Chart
|
|
|
AR
|
LC22T00050F2
|
NAME PLATE INSTALLATION (Replaces LQ22T00064F6)
|
|
6
|
1
|
YN20T01418D3
|
LABEL Decal, Strip 640mm Long (25-3/16 in)
|
