编号（REF）
|
件号(Part No)
|
数量(Qty)
|
品名(Part Name)
|
|
|
708-2L-00461
|
[1]
|
PUMP ASS'Y Komatsu OEM
|
|
|
["SN: 102135-UP"] analogs:["7082L00460"] |$4.
|
|
|
|
|
708-2L-00460
|
[1]
|
PUMP ASS'Y Komatsu OEM
|
|
|
["SN: 99472-102134"] analogs:["7082L00461"] |$5.
|
|
|
|
|
708-2L-00412
|
[1]
|
PUMP ASS'Y Komatsu OEM
|
|
|
["SN: 97283-99471"] analogs:["7082L00151", "7082L00150", "7082L00411", "7082L00413"] |$6.
|
|
|
|
|
708-2L-00411
|
[1]
|
PUMP ASS'Y Komatsu OEM
|
|
|
["SN: 96514-97282"] analogs:["7082L00151", "7082L00150", "7082L00412", "7082L00413"] |$7.
|
|
|
|
|
|
[-1]
|
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-10A0C.
|
|
|
|$$5.
|
|
|
|
|
708-2L-01442
|
[1]
|
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 102135-UP"] analogs:["7082L01440", "7082L01441"] |$13.
|
|
|
|
|
708-2L-01441
|
[1]
|
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 97283-102134"] analogs:["7082L01440", "7082L01442"] |$14.
|
|
|
|
|
708-2L-01440
|
[1]
|
PUMP SUB ASS'Y Komatsu China
|
|
|
["SN: 94999-97282"] analogs:["7082L01441", "7082L01442"] |$15.
|
|
|
|
|
708-2L-04240
|
[1]
|
CASE ASS'Y,FRONT Komatsu
|
|
|
["SN: 94999-UP"] |$16.
|
|
|
|
3
|
07044-12412
|
[1]
|
PLUG Komatsu
|
|
|
["SN: 94999-UP"] analogs:["0704402412", "R0704412412"]
|
|
|
|
4
|
07002-62434
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 102135-UP"] analogs:["7081W28910"]
|
|
|
|
4
|
708-1W-28910
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 94999-102134"] analogs:["0700262434"]
|
|
|
|
5
|
720-68-19870
|
[1]
|
PLUG Komatsu
|
|
|
["SN: 94999-UP"]
|
|
|
|
6
|
07002-61223
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 102135-UP"] analogs:["7082L23940"]
|
|
|
|
6
|
708-2L-23940
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 94999-102134"] analogs:["0700261223"]
|
|
|
|
7
|
04530-11018
|
[1]
|
BOLT,EYE Komatsu
|
|
|
["SN: 102135-UP"]
|
|
|
|
7
|
04530-01018
|
[1]
|
BOLT,EYE Komatsu
|
|
|
["SN: 94999-102134"] analogs:["0453011018"]
|
|
|
|
8
|
708-8E-16150
|
[3]
|
PLUG Komatsu
|
|
|
["SN: 94999-UP"]
|
|
|
|
9
|
07002-61023
|
[3]
|
O-RING Komatsu
|
|
|
["SN: 102135-UP"] analogs:["7082L23920"]
|
|
|
|
9
|
708-2L-23920
|
[3]
|
O-RING Komatsu
|
|
|
["SN: 94999-102134"] analogs:["0700261023"]
|
|
|
|
10
|
708-8H-11530
|
[1]
|
PLUG Komatsu
|
|
|
["SN: 94999-UP"]
|
|
|
|
11
|
07002-61423
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 102135-UP"] analogs:["7082L23950"]
|
|
|
|
11
|
708-2L-23950
|
[1]
|
O-RING Komatsu
|
|
|
["SN: 94999-102134"] analogs:["0700261423"]
|
|
|
|
|
708-2L-00500
|
[1]
|
Pump Assembly Komatsu
|
|
|
["SN: 350001-350614"] analogs:["7082L00501", "7082L00400", "7082L00490"] |$0.
|
|
|
|
|
708-2L-06780
|
[2]
|
Valve Assembly Komatsu China
|
|
|
["SN: 350001-350614"] |$1.
|
|
|
|
1
|
708-2L-35311
|
[1]
|
Sleeve Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
2
|
708-2L-24680
|
[4]
|
Seal Komatsu
|
|
|
["SN: 350001-350614"]
|
|
|
|
3
|
708-2L-35430
|
[1]
|
Spool Komatsu China
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
4
|
708-2L-28540
|
[1]
|
Piston Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
5
|
708-2L-35360
|
[1]
|
Sleeve Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
6
|
708-2L-35331
|
[1]
|
Seat Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
7
|
708-2L-35560
|
[1]
|
Spring Komatsu China
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
8
|
708-2L-35341
|
[1]
|
Seat Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
9
|
708-2L-35351
|
[1]
|
Plug Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
10
|
07000-B1009
|
[1]
|
O-ring Komatsu China
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["7082L23910"]
|
|
|
|
11
|
07001-01009
|
[1]
|
Ring, Back-up Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
12
|
01583-11408
|
[1]
|
Nut Komatsu
|
|
|
["SN: 350001-350614"] analogs:["801713411"]
|
|
|
|
13
|
07002-62434
|
[1]
|
O-ring Komatsu
|
|
|
["SN: 350001-350614"] analogs:["7081W28910"]
|
|
|
|
|
708-2L-00500
|
[1]
|
Pump Assembly Komatsu
|
|
|
["SN: 350001-350614"] analogs:["7082L00501", "7082L00400", "7082L00490"] |$0.
|
|
|
|
|
708-2L-01500
|
[1]
|
Pump Subassembly Komatsu China
|
|
|
["SN: 350001-350614"] |$1.
|
|
|
|
|
708-2L-06450
|
[1]
|
Cap Assembly, End Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] |$2.
|
|
|
|
3
|
708-2L-32260
|
[2]
|
Bearing Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["7082L22260"]
|
|
|
|
4
|
07000-A5165
|
[2]
|
O-ring Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["79398073"]
|
|
|
|
5
|
04020-01228
|
[2]
|
Pin, Dowel Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["21T3016190"]
|
|
|
|
6
|
07000-B2012
|
[11]
|
O-ring Komatsu China
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
7
|
708-2L-25480
|
[4]
|
Filter Komatsu OEM
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
8
|
01010-61655
|
[8]
|
Bolt Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["801015613", "0101031655", "0101051655", "0101081655"]
|
|
|
|
9
|
01643-31645
|
[8]
|
Washer Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["802170005", "0164301645"]
|
|
|
|
|
["SN: 350001-350614"] analogs:["7082L23920"]
|
|
|
|
12
|
708-1L-29340
|
[2]
|
Orifice Komatsu
|
|
1
|
708-2L-32160
|
[1]
|
Shaft,Front Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
2
|
708-2L-32150
|
[1]
|
Bearing Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["7082E12152", "7082L22150", "7082512731"]
|
|
|
|
3
|
708-2E-05040
|
[1]
|
Washer Kit Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["7082E12190"]
|
|
|
|
4
|
708-25-12790
|
[1]
|
Ring, Snap Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
5
|
708-25-52861
|
[1]
|
Seal, Oil Komatsu China
|
|
|
["SN: 350001-350614"] analogs:["7082552860", "7067340920"]
|
|
|
|
6
|
708-2L-22160
|
[1]
|
Spacer Komatsu
|
|
|
["SN: 350001-350614"]
|
|
|
|
7
|
04065-06825
|
[1]
|
Ring, Snap Komatsu
|
|
|
["SN: 350001-350614"]
|
|
|
|
|
708-2L-06470
|
[1]
|
Block Assembly,Front Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] |$13.
|
|
|
|
10
|
720-68-19610
|
[1]
|
Pin Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
11
|
04065-04818
|
[1]
|
Ring, Snap Komatsu OEM
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
12
|
708-2L-23131
|
[1]
|
Seat Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
13
|
708-2L-33160
|
[1]
|
Spring Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] analogs:["7082L23151"]
|
|
|
|
14
|
708-7L-13140
|
[1]
|
Seat Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
15
|
708-2L-23351
|
[1]
|
Guide, Retainer, Retainer Komatsu OEM
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
16
|
708-2L-23360
|
[3]
|
Pin Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
17
|
708-2L-33350
|
[1]
|
Retainer, Shoe, Shoe Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
18
|
708-2L-33430
|
[9]
|
Piston Subassembly Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"]
|
|
|
|
|
708-2L-06630
|
[1]
|
Cradle Assembly Komatsu
|
|
|
["SN: 350001-350614", "SCC: C2"] |$25.
|
|
|
|
22
|
01252-61230
|
[4]
|
Bolt, Hexagon Socket Head Komatsu
|
