编号（REF）
|
数量(Qty)
|
件号(Part No)
|
品名(Part Name)
|
|
14
|
1
|
24165966
|
BRACKET
|
|
13
|
1
|
2437U157F1
|
HYDRAULIC PUMP SEE (C. P. M)
|
|
10
|
1
|
2437U400F1
|
PUMP SEE (C. P. M)
|
|
9
|
1
|
ZD12G05500
|
RING O -- ID 54.40 ± 0.49 x OD 60mm
|
|
8
|
2
|
ZW11K10000
|
WASHER ID 10 x OD 18 x Th 2.0mm
|
|
6
|
13
|
ZS13C10025
|
SCREW M10x1.50x25mm
|
|
5
|
4
|
ZS23C16050
|
SCREW M16x2.0x50mm
|
|
4-7
|
1
|
2418U224S7
|
RUBBER INSULATOR
|
|
4-6
|
8
|
ZP26D05010
|
PIN Roll -- OD 05 x 10mm Long
|
|
4-5
|
2
|
2418U162S3
|
SCREW Set -- M16x2.0x28mm Long
|
|
4-4
|
4
|
2418U128S5
|
SCREW M16x2.0x50mm Long
|
|
4-3
|
4
|
2418U162S2
|
BOLT M16x2.0x16mm Long
|
|
4-2
|
1
|
2418U224S2
|
HUB COUPLING
|
|
4
|
1
|
2418U224F2
|
COUPLING ASSY
|
|
|
AR
|
24100N6211F2
|
|
|
7
|
4
|
ZW22K16000
|
LOCK WASHER ID 16 x OD 24 x Th 3.5mm
|
|
6
|
1
|
2436U1471F3
|
REGULATOR ASSY (R), F2 ONLY, SEE FIGURE 2436U1471-1-3
|
|
5
|
1
|
2436U1472F3
|
REGULATOR REGULATOR ASSY (F), F2 ONLY, SEE FIGURE 2436U1472-1-3
|
|
4
|
1
|
2436R884F1
|
VALVE ASSY, F2 ONLY, SEE FIGURE 2436R884-1
|
|
4
|
2
|
2436R884F1
|
VALVE VALVE ASSY, SOLENOID, F1 ONLY, SEE FIGURE 2436R884-1
|
|
2
|
1
|
2436U1472F1
|
REGULATOR (F), F1 ONLY, SEE FIGURE 2436U1472-1-3
|
|
1
|
1
|
2437U412F1
|
PUMP PUMP ASSY, (NOT IN SERVICE), SEE FIGURE 2437U412-1-3
|
|
|
AR
|
2437U400F2
|
PUMP CONSISTS OF THE FOLLOWING PARTS
|
|
|
AR
|
2437U400F1
|
PUMP CONSISTS OF THE FOLLOWING PARTS
|
|
3
|
1
|
2436U1471F1
|
REGULATOR (R), F1 ONLY, SEE FIGURE 2436U1471-1-3
|
|
|
AR
|
2437U188S530
|
REPAIR KIT CONSISTS OF 531 & 548
|
|
|
AR
|
2437U412S210
|
REPAIR KIT REPAIR KIT, CONSISTS OF REF 212 & 214
|
|
|
AR
|
2437U188S14
|
REPAIR KIT CONSISTS OF REF 141 & 314
|
|
|
AR
|
2437U188S13
|
REPAIR KIT CONSISTS OF REF 141 & 313
|
|
|
AR
|
2437U175S11
|
PISTON REPAIR KIT, CONSISTS OF REF 151 & 152
|
|
983
|
2
|
2437U407S983
|
RIVET
|
|
981
|
1
|
2437U407S981
|
LABEL NAME PLATE
|
|
954
|
2
|
2437U188S954
|
SCREW SET
|
|
953
|
2
|
2437U188S953
|
CAP SETSCREW
|
|
901
|
2
|
ZS91C01000
|
BOLT Eye -- M10x1.50x18mm
|
|
886
|
4
|
ZP26D06014
|
PIN Roll -- OD 06 x 14mm Long
|
|
885
|
2
|
2441U436S886
|
PIN
|
|
824
|
2
|
ZR16X03500
|
RING Retaining -- ID 32.20 x OD 35 x Th 1.6mm
|
|
808
|
4
|
ZN11C16010
|
NUT M16x2.0mm
|
|
792
|
2
|
ZD85G03000
|
BACK-UP RING ID 30 x OD 35 x Th 1.25mm
|
|
789
|
2
|
ZD85P01600
|
RING BACK UP
|
|
774
|
1
|
2441U478S26
|
OIL SEAL
|
|
732
|
2
|
ZD12P01600
|
O-RING ID 15.80 ± 0.20 x OD 20mm
|
|
728
|
3
|
ZD12P01800
|
O-RING ID 17.80 ± 0.21 x OD 22mm
|
|
725
|
2
|
ZD12P01100
|
O-RING ID 10.80 ± 0.18 x OD 15mm
|
|
724
|
18
|
ZD12P00800
|
O-RING ID 07.80 ± 0.16 x OD 11mm
|
|
719
|
2
|
ZD12G11500
|
O-RING ID 114.40 ± 0.94 x OD 120mm
|
|
717
|
2
|
ZD12G12000
|
GASKET O-Ring -- ID 119.40 ± 0.98 x OD 125mm
|
|
710
|
2
|
ZD12G08500
|
O-RING ID 84.40 ± 0.73 x OD 90mm
|
|
702
|
2
|
ZD12G03000
|
O-RING ID 29.4 ± 0.29 x OD 35mm
|
|
548
|
2
|
NSS
|
NOT SERVICED SEPARATELY PIN
|
|
535
|
2
|
2437U188S535
|
STOP
|
|
534
|
2
|
2437U188S534
|
POPPET STOPPER
|
|
532
|
2
|
2437U188S532
|
PISTON PISTON
|
|
531
|
2
|
NSS
|
NOT SERVICED SEPARATELY LEVER
|
|
490
|
15
|
2441U722S490
|
PLUG 1/16" NPTF
|
|
467
|
3
|
2441U436S468
|
PLUG
|
|
466
|
2
|
2441U667S466
|
PLUG 1/4" PF
|
|
407
|
4
|
ZS23C06020
|
SCREW M06x1.0x20mm
|
|
406
|
4
|
ZS23C06016
|
SCREW M06x1.0x16mm
|
|
401
|
8
|
2437U188S401
|
SCREW CAP
|
|
314
|
1
|
NSS
|
NOT SERVICED SEPARATELY PLATE, VALVE
|
|
313
|
1
|
NSS
|
NOT SERVICED SEPARATELY PLATE, VALVE
|
|
312
|
1
|
2437U188S312
|
BLOCK VALVE
|
|
271
|
2
|
2437U188S271
|
CASING
|
|
263
|
1
|
2437U188S263
|
COVER
|
|
261
|
1
|
2437U188S261
|
COVER SEAL
|
|
251
|
2
|
2437U188S251
|
PLATE RETAINER
|
|
214
|
2
|
NSS
|
NOT SERVICED SEPARATELY BUSHING
|
|
212
|
2
|
NSS
|
NOT SERVICED SEPARATELY PLATE
|
|
211
|
2
|
2437U188S211
|
PLATE SHOE
|
|
158
|
2
|
2437U188S158
|
THRUST RING
|
|
157
|
18
|
2437U188S157
|
SPRING
|
|
156
|
2
|
2437U188S156
|
BUSHING
|
|
153
|
2
|
2437U188S153
|
PLATE
|
|
152
|
18
|
NSS
|
NOT SERVICED SEPARATELY SHOE
|
|
151
|
18
|
NSS
|
NOT SERVICED SEPARATELY PISTON
|
|
141
|
2
|
NSS
|
NOT SERVICED SEPARATELY BLOCK, CYLINDER
|
|
127
|
4
|
2441U478S5
|
SPACER
|
|
123
|
2
|
2437U188S123
|
BEARING
|
|
114
|
1
|
2437U188S114
|
COUPLING
|
|
113
|
1
|
2437U412S113
|
SHAFT (R)
|
|
111
|
1
|
2437U188S111
|
SHAFT (F)
|
|
|
AR
|
2437U412F2
|
PUMP ASSY, CONSISTS OF THE FOLLOWING PARTS
|
|
|
AR
|
2437U412F1
|
PUMP PUMP ASSY, CONSISTS OF THE FOLLOWING PARTS
|
|
124
|
2
|
2437U188S124
|
BEARING
|
